flexible structure
The hardware design strives for compactness and saves installation space in the control cabinet.
The plug-in mortise and tenon connection is stable and reliable, and can be replaced in 5 seconds.
Rich selection of accessories
Press in terminal block, quick disassembly without screws.
Supports up to 16 bit precision analog input/output modules (with multiple voltage and current ranges).
PNP and NPN digital input/output modules have a unified backplane bus, which can be expanded both on the host and at remote stations.
one-stop solution
EtherCAT based bus motion control.
Equipped with serial port, CAN interface, support for CANopen and EtherCAT multiple ways of simultaneous expansion, and connected in series with distributed remote I/O stations through a bus.
The CPU host can expand up to 64 modules locally.
High performance Arm processor, 16M program capacity, 64M data capacity, 5M power-off storage capacity.
Single machine controllable with 8 EtherCAT axes, 2ms synchronous with 2 axes, supporting PLCopen motion control commands. Ethernet or serial port is used for monitoring and debugging, supporting the IEC61131-3 programming specification.
100Mbps backplane bus, capable of high-speed response to local or remote station I/O signals.
Rich bus network: Supports EtherCAT, CANopen, CANlink, EtherNet: Modbus TCP master-slave protocol.
FreeTCP, FreeUDP, RS485: Modbus RTU master-slave protocol.
