This device is suitable for labeling canned goods on assembly lines. The main controller is PLC+touch screen input. At the beginning, the frequency converter controls the conveyor belt to move at a lower speed, and then two Maixin EP5 servos act as feed axes to label the products.
High degree of automation, high efficiency, and good stability.
2、 Process requirements
EtherCAT bus control, online diagnosis, remote maintenance
Stable operation for 7 × 24 hours in high dust environment
3、 System solution
The control system adopts a dedicated controller+2 EP5-ECs
Servo power range covers 400W~15kW
4、 Advantages of the plan
Fully automatic detection, remote control
7 × 24-hour stable and fault free operation
Full bus solution, easy to maintain, can provide rich diagnostic information
5、 Equipment Description EP5-EC
Power: 0.4kW~15
Communication interface: EtherCAT
Control mode: Standard DSP402 protocol message, using CSP cycle position control, CSV cycle speed control, CST cycle torque control, HM return to zero mode
A thinner and lighter exterior design significantly reduces installation size
Improved model algorithm for stronger performance
3kHz speed loop response bandwidth
Supports up to 25 bit encoder
Support online inertia recognition, automatic notch, mechanical analysis, and gain adaptation
Bus series products support full closed-loop control
